Автосабвуфер ETON RES 12

ACtivE subwoofer For spare wheel WELLS
RES 12
Technical data RES 12
Music power handling 500 W
Nominal power handling 200 W RMS
Impedance (internal) 2 ohms
Dimensions (L x W x H) 341 x 321 x 164 mm
Weight 9.8 kg
The powerful all-rounder for everyone who wants more bass
in their car – without much effort and without loss of space:
ETON‘s active subwoofer RES 12 can be installed in a spacesaving manner in the spare wheel well or even in the spare
wheel itself (from 15“ rims and up). Thanks to the plug & play
connection system, the bass box is easy to install and to
remove, 100% retrofittable – and therefore also ideal for
leased vehicles.
The powerful spare wheel active subwoofer comes in a highquality, solid die-cast aluminum enclosure. The 30 cm/12“
woofer with a heavy-duty 2 ohms voice coil is powered by
the integrated amplifier module with 500 watts. The result:
pure performance and rich, crisp bass with optimized depth!
The active bass box is engineered in Germany and equipped
with an integrated 50 – 120 Hz low-pass filter and an RCA
input (low level input). For connection to factory radios without
a REM output, the RES 12 has a high-level input with an auto
turn-on function.
All controls are on the wired remote control that is included.
Active operation without a remote control (control via DSP/
head unit) is possible via a bypass plug.
key features RES 12
• Rigid sealed die-cast aluminum enclosure
• Class A/B active module with 500 W music power handling
• 30 cm/12“ woofer with heavy-duty 2 ohms voice coil and
large hole for center clamp rod
• Integrated low-pass filter 50 Hz – 120 Hz
• Phase shift: 0°/180°
• RCA (cinch) low level input
• Connector plug with integrated high-level input
• Auto turn on function
• Suitable for vehicles with start-stop function
• Engineered in Germany
• Scope of delivery: RES 12, 18 pin connection harness (+12 V
power cable, remote cable, speaker input, ground), 6 m
power cable (10 AWG) with integrated fuse holder 25 A,
loudspeaker cable, wired level remote control, strain relief
& mounting accessories, bypass plug for omitting the wired
remote control (amplifier works in full range mode)
